EDEY MANUFACTURING
DOOR CLOSER, 18" ASSEMBLY
LIST PRICE $ 797.50
YOUR PRICE $ 797.50
-
+


ADD TO CART
MFR Part #: 55-18
RHS Part #: 08-115
IN STOCK:CAYES
 COYES

PRODUCT INFORMATION

RHS NOTES

THIS CLOSER WORKS ON FLUSH DOORS UP TO A 7/8" OFFSET.

FINISH IS PAINTED, NOT ZINC.

REVERSIBLE FOR LEFT OR RIGHT HAND DOORS.

USE ON DOORS NO LARGER THAN 3' WIDE AND 7' HIGH. WEIGHT RATING IS UP TO 200LBS. FOR DOORS LARGER THAN 3' WIDE AND 7' TALL, SEE P/N 08-121

SPRING TENSION INSTRUCTIONS:
WHEN MOUNTED ON RIGHT HINGED DOORS THE CLOSER IS APPLIED WITH THE ARM TOWARDS THE TOP OF THE CLOSER.

WHEN MOUNTED ON LEFT HINGED DOORS THE CLOSER IS APPLIED WITH THE ARM TOWARDS THE BOTTOM OF THE CLOSER.

DOOR CLOSER IS EQUIPPED WITH A 90/80 DEGREE, AND 180 DEGREE HOLD OPEN FEATURE. OPEN DOOR TO THE DESIRED POSITION WHILE INSERTING THE PAWL IN RATCHET COLLAR CLOSER. THIS REMOVES SPRING POWER TENSION FROM CASING.
TO CLOSE, OPEN THE DOOR ENOUGH TO UNTENSION THE PAWL. THE CLOSER WILL THEN AUTOMATICLY RELEASE THE PAWL AND THE CLOSER WILL CLOSE THE DOOR.
WHEN USED AT 180 DEGREES THE PAWL MAY NEED TO BE RELEASED BY HAND. EXTREME CAUTION SHOULD BE USED IN THIS INSTANCE TO PREVENT ANY ACCIDENTS. DOOR CLOSER IS DESIGNED TO BE USED WITH BOTH STRAP AND CAM-LIFT STYLE HINGES.


!!OVERTENSION CAUTION!!
DO NOT APPLY MORE TENSION THAN IS NECESSARY TO THE CLOSER.

ON INSTALLATION, AFTER APPLYING SOME TENSION TO THE CLOSER, OPEN THE DOOR TO 60 DEGREES AND RELEASE IT (A DOOR IS USUALLY OPENED AT LEAST 60 DEGREES). IF IT CLOSES PROPERLY, THERE IS SUFFICIENT TENSION. THE FURTHER THE DOOR IS OPENED, THE MORE SPRING POWER IS DEVELOPED TO START CLOSING THE DOOR. THUS, THE MOMENTUM IS INCREASED AS THE DOOR MOVES TO THE CLOSED POSITION. ALWAYS APPLY TENSION TO THE SPRING IN SMALL INCREMENTS TO KEEP FROM BREAKING THE SPRING AND VOIDING YOUR WARRANTY.

WARRANTY INFORMATION:
NOTE THIS IS A RETURN AND REPAIR ITEM ONLY! TYPICALLY THE SPRING IS OVER-TENSIONED AND SNAPS. WARRANTY RESTRICTIONS MAY APPLY IN THESE INSTANCES. PLEASE CONTACT A SERVICE REPRESENTATIVE.
